Neutron Scattering and Beamline Systems

Click image to enlarge
Click image to enlarge
Click image to enlarge
Click image to enlarge
Click image to enlarge

For optical, neutron and particle beam experiments, Cryogenic offers a range of split pair magnets.  These allow strong magnetic fields to be produced in a small volume with maximum access to the working space.  Split pair coils can be mounted to provide either a vertical field with horizontal access or a horizontal field offering horizontal or vertical access.

Large windows in the support structure between the coils allow access to the sample.  For other applications a thin walled aluminium former and aluminium windows  also allows transmission of the beam.





Key Features

• Room-temperature bore or integrated cryogen-free 1.6 K-300 K VTI
• Symmetric superconducting split-pair magnets up to 14 T
• Asymmetric magnets for use in polarised neutron experiments up to 7 Tesla
• Large apertures for incoming and scattered neutrons
• High purity thin Aluminium, Beryllium or Vanadium windows in cryostat outer, radiation shield, Magnet and VTI.
• Low vibration pulse tube allowing up to 30,000 hours of continuous operation.
• Easy to use: no cryogenic experience required
• Supplied with LabVIEW® software suite as standard.
